F304L Anti Static Blowout Proof Forging Type Ball Valve

Basic Information
Place of Origin: CHINA
Brand Name: COOSAI
Certification: API6D API6F
Model Number: Q41F
Packaging Details: PLYWOOD CASE
Detail Information
Temperature: -29℃-425℃ Body Material: CF8M/CF8/WCB
Seat Material: PTFE/RPTFE/NYLON/DEVLON Operation: Manual/Pneumatic/Electric
Pressure: Class 150-900 Fire Safe: API 607/API 6FA
Connection Type: Flanged Name: F304L Flanged Floating Ball Valve
High Light:

Anti Static Forging Type Ball Valve


F304L Forging Type Ball Valve


Anti Static Forging Type Ball Valve F304L

Product Description

Product Description:

Floating Ball Valve is a kind of forging type ball valve designed and manufactured according to API 6D, API 608 and BS 5351 standards. It has excellent anti-static performance, and its end connection is available in RF, RTJ and BW types. It is capable of working under pressure ranging from Class 150 to Class 900, and its available size is from 2 inch to 24 inch.



  • Product Name: Floating Ball Valve
  • Forging Type Ball Valve, Two Piece Ball Valve, floating type ball valve
  • Stem Packing: PTFE/Graphite/PEEK
  • Anti-Static: API 608
  • Fire Safe: API 607/API 6FA
  • Test Standard: API 598/API 6D

Technical Parameters:

Parameter Value
Name F304L Flanged Floating Ball Valve
Connection Type Flanged
Design Standard API 6D/API 608/BS 5351
Pressure Class 150-900
Size 2-24 inch
Fire Safe API 607/API 6FA
Test Standard API 598/API 6D
Ball Material CF8M/CF8/WCB
Operation Manual/Pneumatic/Electric


The F304L Flanged Floating Ball Valve, with its 2-piece structure, is designed for use in a variety of applications, from low to high pressure. It is forged with quality materials, such as CF8M, CF8, and WCB, and the stem packing is made of PTFE, graphite, and PEEK. The seats are available in PTFE, RPTFE, nylon, and Devlon, and it is rated for pressures from Class 150 up to Class 900. This floating type ball valve is an ideal choice for a reliable, durable, and cost-effective solution for many industries.

Support and Services:

Floating Ball Valve Technical Support and Service

We provide comprehensive technical support and service for our Floating Ball Valve customers. Our experienced technical team is always available to answer questions and concerns related to the installation and operation of the valve. We offer on-site support and troubleshooting for any issues that may arise.

We also offer a range of after-sales services such as product training, spare parts supply, and maintenance services. Our after-sales services are designed to help customers maximize the benefits of their Floating Ball Valve investments.

We pride ourselves on providing the highest level of customer service and support. Our technical team is available 24/7 to respond to any customer inquiries or requests.


Packing and Shipping:

Floating Ball Valves must be packaged and shipped with care. All valves are inspected and tested prior to shipping. The following instructions must be followed to ensure safe delivery and proper functioning of the valves:

  • Carefully package each valve in its original box, or in a box with similar specifications.
  • Pack the valves with a foam core for added protection.
  • Seal the box with strong tape, making sure all seams are secure.
  • Label the box clearly with the product name, model number, and customer's name and address.
  • Insure the shipment for the full value of the product.
  • Ship the valves via a reliable carrier that offers tracking and delivery confirmation.


  • Q: What is Floating Ball Valve?
  • A: Floating Ball Valves are valves that use a floating ball to control the flow of liquids and gases. They are commonly used in process control applications in industrial plants.
  • Q: What are the key advantages of using Floating Ball Valves?
  • A: Floating Ball Valves have several key advantages, such as a tight shutoff, low pressure drop, and minimal maintenance requirements.
  • Q: What types of materials are used in Floating Ball Valves?
  • A: The bodies of Floating Ball Valves are usually made from brass, stainless steel, or other materials such as carbon steel, cast iron, or plastic.
  • Q: What is the range of sizes for Floating Ball Valves?
  • A: Floating Ball Valves are available in sizes ranging from 1/4” to 4”.
  • Q: What is the temperature range for Floating Ball Valves?
  • A: Floating Ball Valves are typically designed to operate under temperatures ranging from -20°F to 400°F.F304L Anti Static Blowout Proof Forging Type Ball Valve 0F304L Anti Static Blowout Proof Forging Type Ball Valve 1F304L Anti Static Blowout Proof Forging Type Ball Valve 2
