Manual Through Conduit Stainless Steel Gate Valve

Basic Information
Place of Origin: China
Brand Name: Coosai
Certification: ISO
Model Number: DN50-DN600
Minimum Order Quantity: 1PC
Price: Price negotiable
Packaging Details: plywood case
Delivery Time: 40days-60days
Payment Terms: L/C, T/T
Supply Ability: 100pcs per day
Detail Information
Size: DN50-DN600 Material: Stainless Steel
Media: Pulp And Paper/ Mining /Waste Water Treatment/ Food And Beverage/Chemical Plants/ PowerPlants/ Steel Industry Certificate: ISO
Actuator: Hand Wheel, Electric ,Pneumatic (single & Double-acting), Chain Wheel ,Hydraulic Connection: Wafer , Lug Type
High Light:

dn250 knife gate valve


through conduit ss gate valve


coosai stainless steel gate valve

Product Description

Manual Through Conduit Knife Gate Valve,Lug Type/Wafer Type



Technical Data


DN 50 to DN 600 (larger diameters on request)


Actuator :

Hand wheel, Electric ,Pneumatic (single & double-acting),

Chain wheel ,Hydraulic


Standard flange connection:

GB/T 9113.1-2000,JB/T 79.1-1994,HG 20592-2009

ASME B 16.5 EN 1092-1:2001


Seat Material:

Resiliant: PTFE/EPDM/NBR

Metal: Tungsten Carbide/Satellite/304/316


Face to face standard:

MSS SP 81-2001,GB/T 12221-2005J16



CE, ISO9001 Accredited



Pulp and Paper/ Mining /Waste Water Treatment/ Food and Beverage/Chemical Plants/ PowerPlants/ Steel Industry/Etc.



1. Lug water knife gate valve:DN50-DN600

Pressure rating:DIN PN10,PN16,ANSI 150

2. Wafer thtough conduit knife gate valve:DN50-DN600

Pressure rating:DIN PN10,PN16,ANSI 150




1. Integral body design,small flow resistance,smooth operation.

2. Stem drive is designed with 2plane bearings,the driving friction is greatly reduced so making operation of valve become smooth and light.

3. Seat with moveable sealing design and O-ring can provide a preloading force to push the seat sealing ring touching tightly with gate which can probide a self compensation to the sealing surface when it had been worn after long time in service,so its service life can be increased.

4. Fixed guide claw,without groove design,so medium is not easy to be accumulated and blocked.

5. Material of seat is selected according to the medium and service condition,choosing metal seal or soft seal.Metal seal with gate surface is coated with hard chtomium,or Nitriding treatment,to increase its wear resistance.Soft seal will be with PTFE seat,or EPDM,NBR,which have good sealing performance and excellent corrosin resistance.

6. With excellent sealing performance and economical practicality,and its operation can be by manual,pneumatic or electric actuator,so its application is very wide.


Manual Through Conduit Stainless Steel Gate Valve 0

Manual Through Conduit Stainless Steel Gate Valve 1
